| Aperture | 700mm | |
| Rotation times in sec. | 0,5; 0,75; 1; 1,5; 2 | |
| Tilt degrees | -30° to +30° / 0,5° increments | |
| Focus-Detector-Distance | 1040mm | |
| Focus-Isocenter-Distance | 570mm | |
GENERATOR
| Output capacity | 48 kW | |
| kV | 90, 120, 140 kVp | |
| mA | 20-400 / 1mA increments | |
X-RAY TUBE CTR 2185
| Storage Capacity | 5 MHU | |
| Cooling Rate | 815 kHU/min | |
| Focus large | 1 x 1 mm | |
| Focus small | 0,5 x 1mm | |
| Target angle | 7° | |
DETECTOR – GOS 16128 Elements
| Slice Collimators | 2 x 0,6mm, 6 x 0,75mm, 6 x 1,5mm | |
| 6 x 3,0mm, 4 x 6,0 mm | ||
| Slice Thickness Spiral | 0,65 – 7,5mm variable | |
| Slice Thickness Axial Mode | 0,6 – 12mm | |
| Scan angles | 240°, 360°, 420° | |
| Field of view | 250mm, 500mm | |
COMPUTER SYSTEM
| Host Computer | Dell, Windows XP, 2GB RAM, optional 4GB | |
| Reconstructor | Rapid View | |
| Reconstruction Time | 6 ips at 512² matrix, opt. 20ips | |
| FOV continuos | 50 to 500mm | |
| FOV Ultra High Mode | 25 to 250mm | |
| Image Matrix | 512² (optional 768² and 1024²) | |
COUCH
| Vertical Range | 60kW | |
| Longitudinal speed | 90, 120, 140kVp | |
| max. Load | 20-500 / 1mA increments | |
